Request For Our Latest Prices On ZERON 100 Bolts in Mumbai, India!
The Fasteners Mart, based in Mumbai, India, is a reliable and prominent manufacturer of high-quality industrial fasteners, renowned for providing precision-engineered products to diverse industries. With years of experience and dedication to excellence, The Fasteners Mart provides an extensive variety of fasteners meeting international standards, guaranteeing exceptional performance and longevity. Our organization specializes in supplying fasteners in numerous grades, sizes, and materials to industries including petrochemical, marine, construction, and engineering. We are proud of timely delivery, best pricing, and world-class customer service.
ZERON 100 bolts are composed of high levels of nickel, chromium, molybdenum, and copper, with trace elements of nitrogen and tungsten. This blend ensures exceptional resistance to corrosion, particularly in harsh environments such as seawater and acidic conditions. Known for their robustness and reliability, ZERON 100 bolts offer outstanding durability, strength, and ease of maintenance. They are preferred in critical applications across industries like offshore oil and gas, chemical processing, and marine engineering, where reliability and longevity are paramount.
| % | Cr | Ni | Mo | Cu | W | C | N | Mn | Si | P | S | Fe |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Min | 24 | 6 | 3 | 0.5 | 0.5 | – | 0.2 | – | – | – | – | – |
| Max | 26 | 8 | 4 | 1 | 1 | 0.03 | 0.3 | 1 | 1 | 0.030 | 0.010 | Balance |
| Mechanical & Physical Properties | -70°C | -46°C | 21.1 °C | 93.3°C | 148.9 °C | 204.4 °C | 250 °C | 300°C |
|---|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength, MPa | – | – | 750 | 670 | 620 | 610 | 600 | 590 |
| 0.2% Yield Strength, MPa | – | – | 550 | 430 | 400 | 380 | 370 | 360 |
| Reduction of area % | – | – | – | – | – | – | – | – |
| Elongation % | – | – | 25 | – | – | – | – | – |
| UNS S32760 Fg Bolts, Studs Threads: | METRIC, BSW, BSF, UNC, UNF or as required |
|---|---|
| Zeron 100 Threaded Rod Standard: | ANSI – American National Standards Institute
|
| Zeron 100 Fasteners Material Specification | Zeron 100 Fasteners , UNS S32760 Bolts |
| S32760 Fasteners / Bolts Standard | DIN, UNI, ISO, JIS, GB, IS, BS, ASME, ANSI, ASTM and all International Standards |
| 1.4501 UNS S32760 Fasteners/ Bolts Size | M2, M2.5, M3, M4, M5, M6, M8, M10, M12, M14, M16, M20, M24, M30, M36 to M160 |
| Length of S32760 Hex Bolt | 3 mm to 200 mm |
| Source of raw materials to manufacture 1.4501 UNS S32760 Screw | Tata Steel, JSPL, RINL, Usha Martin, Dhamm Steel, Mukund Steel etc. |
| Zeron 100 Hex Bolt Thread | Metric Coarse |
| S32760 bolting Test Certificate: | Manufacturer Test Certificate as per EN 10204 / 3.1 |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
ZERON 100 Bolts find broad usage in those industries that require the highest levels of corrosion resistance and strength. Standard applications cover offshore oil and gas platforms, subsea components, desalination plants, and marine engineering. These bolts are used in chemical processing plants, heat exchangers, and power generation units. On account of their resistance to chloride-induced stress corrosion and superior mechanical properties, the ZERON 100 bolts are well suited for aggressive environments with seawater, acids, and other corrosive media. Their dependability and durability make them a popular choice in high-stress fastening applications.
