Request For Our Latest Prices On SS 317/317L Stud Bolts in Mumbai, India!
The Fasteners Mart, which is based in Mumbai, India, is a reliable manufacturer and supplier of top-quality fasteners, such as Stainless Steel 317/317L Stud Bolts. Popular for their impeccable corrosion resistance and longevity, our stud bolts are designed to excel in the toughest industrial requirements. Prioritizing precision and consistency, we produce products that deliver superior performance in diverse industries at home and around the world.
Stainless Steel 317/317L Stud Bolts consist mainly of iron, with chromium content of about 18-20% and nickel content of 12-15% to provide corrosion resistance. Molybdenum (3-4%) addition also provides pitting and crevice corrosion resistance. Mechanical properties are tensile strength of about 650 MPa and yield strength of 290 MPa. These stud bolts contain good toughness along with excellent corrosion resistance, thanks to which these are used at high temperatures under aggressive conditions. The lower amount of carbon contained in 317L makes welding easier.
Material | Specification | Standards | Size | Length |
Stainless Steel 317 / 317L Stud bolt
| IS BS ASTM | ASTM / ASME – A/ SA 193 | 3 mm | M02 to M33 |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 317 | 620 MPa | 275 MPa | 45% | 85 | 193 |
| 317L | 595 MPa | 260 MPa | 55% | 85 | 200 |
| Grade | C | Mn | Si | P | S | Cr | Ni | Mo | N |
| SS 317 | 0.08 max. | 2.00 max. | 1.00 max. | 0.045 max. | 0.03 max. | 18.0 – 20.0 | 11.0 – 14.0 | 3.0 – 4.0 | – |
| SS 317L | 0.03 max. | 2.00 max. | 0.75 max. | 0.045 max. | 0.03 max. | 18.0 – 20.0 | 11.0 – 15.0 | 3.0 – 4.0 | 0.1 |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Stainless Steel 317/317L Stud Bolts have extensive applications in industries that need superior corrosion resistance, including chemical processing, petrochemical and power generation. They find application in high-temperature operations, including pressure vessels, reactor vessels, and heat exchangers. These stud bolts find applications in food processing, marine and pharmaceutical industries because they are resistant to chloride-induced corrosion. Their toughness and resistance make them ideal for severe structural and mechanical uses, especially where better performance is required in harsh conditions.
Our Stainless Steel 317/317L Stud Bolts are accompanied by a comprehensive documentation package prepared to meet and surpass client needs. The package comprises commercial invoices, packing lists, fumigation certificates, heat treatment certificates, quality assurance plans, and certified laboratory test reports. Apart from that, we offer a complete set of test certificates including MTC in compliance with EN 10204/3.1b, PMI test reports, 100% radiography reports and Third-Party Inspection Certificates. Our commitment to thorough documentation and rigorous quality testing guarantees absolute client satisfaction in each delivery.
The Fasteners Mart is a leading manufacturer and supplier of high-quality fasteners in Mumbai, India, with over 8 years of experience serving global industries.
