Request For Our Latest Prices On Stainless Steel 316h Stud Bolts in Mumbai, India!
The Fasteners Mart, Mumbai, India, is a reliable industrial fastener manufacturer and exporter with a varied selection of high-performance products. Their high-quality product line includes Stainless Steel 316H Stud Bolts that are produced from high-carbon austenitic stainless steel. The bolt comes in threaded rod or double-ended forms and is particularly constructed for applications in high-temperature and high-pressure conditions. Grade 316H offers great mechanical strength, creep resistance, and increased corrosion resistance, making these stud bolts suitable for petrochemical, power, and marine applications.
Stainless Steel 316H Stud Bolts have chromium (16–18%), nickel (10–14%), molybdenum (2–3%), and increased carbon content (0.04–0.10%) that adds strength at higher temperatures. The bolts provide a tensile strength of approximately 515 MPa, yield strength of 205 MPa, and hardness of up to 217 HB. Having a density of 8.0 g/cm³ and great resistance to corrosion and oxidation, they serve dependably in corrosive chemical and high-heat environments and withstand long-term thermal stress with no loss of structural integrity.
| Fasteners Material Specification | ASTM A194, ASME SA193, UNS S31609 Bolts |
|---|---|
| Standard | DIN, UNI, ISO, JIS, GB, IS, BS, ASME, ANSI, ASTM and all International Standards |
| Fasteners/ Bolts Size | M2, M2.5, M3, M4, M5, M6, M8, M10, M12, M14, M16, M20, M24, M30, M36 to M160 |
| Length | 3 mm to 200 mm |
| Bolts, Studs Threads: | METRIC, BSW, BSF, UNC, UNF or as required |
| SS 316h Fasteners Standard: | ANSI – American National Standards Institute
|
| Source of raw materials | Tata Steel, JSPL, RINL, Usha Martin, Dhamm Steel, Mukund Steel etc. |
| SCOPE OF MANUFACTURE |
|
| Fasteners In Form of: | Hex, Square, Round, Threading as per Gauge Etc. |
| Head drive: | Phillips, Slotted, Phillips/Slot, Six-Lobe, etc |
| bolting Test Certificate: | Manufacturer Test Certificate as per EN 10204 / 3.1 |
| Fasteners finishing: | Zinc (yellow, white, blue, black), black oxide, Geometry, Dacroment, anodizing, nickel plated, plated zinc-nickel, Stainless steel: Passivated Self-Colour, Hot Dip Galvanised (HDG), Bright Zinc Plated (BZP), Sherardized, Stainless Steel, Mechanically Applied coating and some special one like DACROMET |
| Production process | M2-M24: Cold Froging, hot forging M24-M100, machining and CNC for Customized connecting element |
| bolting materials Surface Coating: |
|
| Popular Types of SS 316h Bolts | Hex Bolts, Flange Bolts, Hex Head Bolts, Lag Bolts, Square Bolts, Eye Bolts, U Bolts, T Bolts, Counter sunk Bolts etc. |
| Popular Types of SS 316h Nut | Hex Head Nut, Eye Nut, Dome Nut, Wing Nut, T Nut, Panel Nut, Lock Nut, Coupling Nut, Square Nut, Acorn Nut etc. |
| Popular Types of SS 316h Screw | Hex Head Cap Screws, Socket Set Screws, Anchor Screws, Blind Rivet, Socket Head Screws, Concrete Screws, Shoulder Screws, Panel Screws, Threaded Screws, Machine Screws etc. |
| Popular Types of SS 316h Washer | Machine Washers, Flat Washer, Star Washers, Sealing Washer, Lock Washer, Split Washer etc. |
| Our stockyad location for fast delivery in India | Noida, Bengaluru, Pimpri-Chinchwad, Thiruvananthapuram, Tirunelveli, Vasai, Dhanbad, Chennai, Agra, Nagpur, Hyderabad, Kolkata, Coimbatore, Pune, Jaipur, Tiruchirappalli, Shivamogga, Ahmedabad, surat, Bhubaneswar, Thane, Nashik |
| Fasteners Packing: | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
|
Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
|
|
316H |
Min |
0.04 |
0.04 |
0 |
– |
– |
16.0 |
2.00 |
10.0 |
– |
|
max |
0.10 |
0.10 |
0.75 |
0.045 |
0.03 |
18.0 |
3.00 |
14.0 |
– |
|
Grade |
Tensile Str
(MPa) min |
Yield Str
0.2% Proof
(MPa) min |
Elong
(% in 50mm) min |
Hardness |
|
|
Rockwell B (HR B) max |
Brinell (HB) max |
||||
|
316H |
515 |
205 |
40 |
95 |
217 |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Stainless Steel 316H Stud Bolts are widely utilized in high-temperature critical applications like in boilers, refineries, heat exchangers, and power plants. Their resistance towards corrosive substances and strong construction make them suited for chemical processing systems and marine structures. These stud bolts are well-suited for flanged connections, pressure vessels, and structural support at high temperatures and aggressive conditions. Their reliability and high mechanical performance qualify them as a reliable option in oil & gas, shipbuilding, and thermal engineering uses.
The Fasteners Mart ensures safe and timely delivery of Stainless Steel 316H Stud Bolts worldwide. Each item is properly packaged with moisture-proof materials, bubble wrap, and heavy-duty wooden crates or boxes to avoid damage in transit. Each shipment is marked and checked for accurate, quality-oriented delivery.
The Fasteners Mart is a leading manufacturer and supplier of high-quality fasteners in Mumbai, India, with over 8 years of experience serving global industries.
