Request For Our Latest Prices on Stainless Steel 304L Stud Bolts in Mumbai, India!
The Mumbai, India-based Fasteners Mart is a well-known industrial fasteners supplier of superior quality. They deal in a wide range of fasteners, such as Stainless Steel 304L Stud Bolts, that are made to last and exhibit outstanding corrosion resistance. These bolts are manufactured from Grade 304L stainless steel and are ideal for application in chemical processing, food processing, and marine environments. In a variety of sizes and forms, Stainless Steel 304L Stud Bolts provide superior strength and resistance, and are therefore suited for severe service applications in hostile environments.
304L Stainless Steel Stud Bolts are constructed from austenitic stainless steel with 18-20% chromium and 8-12% nickel composition. The reduced carbon facilitates weldability and avoids intergranular corrosion. The bolts exhibit superior resistance to oxidation and corrosion in all environments, especially acids and salts. The mechanical properties are a tensile strength of 520 MPa and yield strength of 205 MPa. With excellent ductility and formability, they are best used in severe temperature conditions, tolerating up to 870°C (1600°F) temperature.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304L | 0.035 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 13 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 550 | Psi – 30000 , MPa – 205 | 35 % |
| Specification | ASTM A 193/ASME SA 193 |
| Standard | all International Standards and ASTM, DIN, BS |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Length | 3 mm to 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin,etc. |
| Packing | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Cadmium Coating Hot Dipped Galvanizing Coating Ptfe Coated Phosphate Coating Teflon Coating Xylon Coating Zinc Coating |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Stainless Steel 304L Stud Bolts find extensive applications in industries demanding high corrosion resistance, like chemical, pharmaceutical, food processing, and marine applications. These bolts are perfectly suited for bolted joints in piping systems, tanks, and heat exchangers. Their high strength and resistance to chemicals and rust render them the most sought-after material for applications demanding long-term performance under severe environmental conditions. They are also utilized in structural purposes, providing durability and reliability to key machinery and equipment.
The Fasteners Mart offers effective delivery and packaging solutions for Stainless Steel 304L Stud Bolts. The bolts are safely packaged to reach in good condition, with the option of custom packaging according to customer needs. The company ensures timely and reliable shipping, with the products being delivered on time, meeting industry standards for quality and customer satisfaction.
The Fasteners Mart is a leading manufacturer and supplier of high-quality fasteners in Mumbai, India, with over 8 years of experience serving global industries.
