Request For Our Latest Prices On Inconel 718 Fasteners in Mumbai, India!
The Fasteners Mart, Mumbai, India, is a renowned producer and exporter of high-performance industrial fasteners for a variety of industries all over the world. Among its high-end products are Inconel 718 Fasteners, produced with Grade Inconel 718, a high-strength, nickel-chromium alloy. The fasteners are made in a variety of shapes such as bolts, nuts, screws, washers, and studs. Inconel 718 has been recognized for its superior high-temperature, oxidation, and corrosion resistance, combined with excellent tensile and fatigue strength. Due to these properties, it has become a sought-after material in demanding applications such as aerospace, chemical, marine, and power generation industries.
Inconel 718 Fasteners consist mainly of 50–55% nickel, 17–21% chromium, 4.75–5.5% niobium, 2.8–3.3% molybdenum, and traces of titanium, aluminum, and iron. They have a tensile strength of more than 1300 MPa, with good yield strength and creep resistance up to 700°C. The alloy has superior fatigue and corrosion resistance at both high and cryogenic temperatures. With a specific gravity of 8.19 g/cm³ and a melting range of 1260°C to 1336°C, these fasteners are suitable for harsh environments and long-term use.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 50.00 – 55.00 | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
| Specifications | ASTM B166 / ASME SB166 |
|---|---|
| Fasteners size | Bolt / Screw Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Nuts Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Washers Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Machine Screws Size : M1.6 – M12 Self Tapping Screw Size : No.2 – No. 14 |
| Fasteners Length | 3 mm to 200 mm |
| Fastener Threads | UNF, BSW, BSF, METRIC, UNC or as required |
| Standard of High Nickel Alloy Fasteners | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Stud Bolt length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Surface Coating | Ptfe Coated High Nickel Alloy Fasteners Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Inconel 718 Fasteners find extensive applications in aerospace engine, gas turbine, nuclear reactors, oil and gas drilling equipment, and chemical processing plant equipment. Their good strength and resilience to intense pressure and heat enable them to perform well in jet engines and exhaust systems. The fasteners find use in energy and offshore applications due to their capability to bear corrosive media and mechanical stresses. Further, their non-magnetic properties and stability at cryogenic temperatures permit application in superconducting technologies and high-vacuum applications where precision and performance are key.
All Inconel 718 Fasteners at The Fasteners Mart are safely packaged with moisture-proof wrapping, foam padding, and durable export-grade boxes or wooden crates. Every shipment is marked for traceability and packed to avoid transit damage. We provide safe and timely delivery to domestic and international destinations, with customized packaging to suit specific client or project needs.
The Fasteners Mart is a leading manufacturer and supplier of high-quality fasteners in Mumbai, India, with over 8 years of experience serving global industries.
