Home > Inconel 617 Washers
Request For Our Latest Prices On Inconel 617 Washers in Mumbai, India!
the Mumbai, India-based company Fasteners Mart. Because of their higher heat and corrosion resistance, Inconel 617 washers are used in high-critical operation in the power generation, aerospace, and gas turbine industries. We, at The Fasteners Mart, ensure the maximum quality standards of our products with washers that are resistant to breakdown and consistent in poor conditions. Our reliability and precision-driven approach have enabled us to be the top-most preference for businesses requiring high-performing fasteners that are hardy and durable.
Inconel 617 washers are made of a nickel-chromium alloy with approximately 50-60% nickel, 20-23% chromium, and cobalt, molybdenum, titanium, and aluminum. The alloy provides good resistance to carburization, oxidation, and corrosion at elevated temperatures. Inconel 617 washers are mechanically robust with tensile strength of approximately 880 MPa and yield strength of approximately 450 MPa at high temperatures. These washers retain their strength and structural integrity even in thermal cycling, high-pressure, and corrosive conditions, and are therefore best suited for high-performance applications in gas turbines, aerospace, and power generation.
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
Standard ASTM B168 / ASME SB168
Dimensions DIN 125/127, ISO 7089/7090, ASME B18.22.1
Type Cold Forged, Hot Forged, Bar Stock Machined, Bar Stock Milling
Size M02 to M33
Length 3 mm to 200 mm
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Inconel 617 washers are used in very diverse applications in pressure, corrosion-resistant, and high-temperature application in industries. The areas of use are power generation equipment, gas turbines, and aerospace engines, where they are used as the sealing and fastening elements of critical significance. Inconel 617 washers are most suitable for high-temperature use like combustion chambers, heat exchangers, and reactors, where they offer reliability and long life under severe thermal cycling and stress. Inconel 617 washers are also used in petrochemical, chemical processing, and nuclear power plants with effective sealing and resistance to carburization and oxidation damage under harsh conditions. They have no match when performance is concerned with respect to challenging industries.
Inconel 617 washers are properly packaged for handling and shipping safely. They are typically packaged in wooden cases or durable boxes with a buffering substance like bubble wrap or foam to cushion them against any potential damage during delivery. The packages are well-labeled for recognition. Inconel 617 washers undergo rigorous testing prior to shipping. They undergo dimensional inspection, composition analysis, and mechanical property inspection. These tests guarantee that the washers meet industry standards for strength, durability, and resistance to corrosive and high-heat conditions.
The Fasteners Mart is a leading manufacturer and supplier of high-quality fasteners in Mumbai, India, with over 8 years of experience serving global industries.
