Home > Inconel 617 Stud Bolts
Request For Our Latest Prices On Inconel 617 Stud Bolts in Mumbai, India!
Fasteners Mart, Mumbai, India, is a trusted manufacturer and exporter of high-quality fasteners, including Inconel 617 stud bolts. Inconel 617 stud bolts are designed to provide high performance in aggressive and high-temperature environments with superior strength and corrosion resistance and are thus appropriate for challenging applications in aerospace industries, power plants, and gas turbines. At The Fasteners Mart, precision and reliability come first, and our products are designed to the highest level of performance in high-temperature and high-stress environments, making us a preference for industrial fastening applications.
Inconel 617 stud bolts are composed of a nickel-based high-performance alloy containing around 50-60% nickel, 20-23% chromium, 9-12% cobalt, and molybdenum, titanium, and aluminum. This precise composition exhibits superb resistance to high-temperature corrosion, carburization, and oxidation. Inconel 617 stud bolt mechanical properties include tensile strength of around 880 MPa and yield strength of around 450 MPa at elevated temperature (900°C). These bolts possess higher strength and structural integrity under extreme thermal cycling and stress and are most suitable for application in high-temperature environments like gas turbines, aerospace, and power generation.
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
Standard ASTM B168, B166 / ASME SB168, SB166
Dimensions ANSI B18.2.1, DIN 931,DIN 933, ISO 4014, ISO 4017,BS 1768, BS1768, IFI 115
Threads Configuration ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads
Type Cold Forged, Hot Forged, Bar Stock Machined, Bar Stock Milling
Size M02 to M160
Length 3 mm to 200 mm
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Inconel 617 stud bolts are extensively used in applications that involve high temperature and stress due to their superior strength, heat stability, and oxidation resistance. They find wide application in gas turbines, power generation machines, and airplane engines and serve to secure sensitive components that need to function at very high temperatures and corrosive environments. These stud bolts are also used in heat exchangers, reactors, and combustion chambers where they provide reliable performance under thermal cycling and pressure. Inconel 617 stud bolts are also used in petrochemical, chemical processing, and nuclear power plants to offer durability and efficiency in harsh industrial applications.
Inconel 617 stud bolts are individually packaged when shipping for preventing damage. They are suitably packaged in stiff wooden crates or boxes, and other protective materials like foam or bubble wrap for secure shipping. Packages are suitably tagged to facilitate identification and handling. Inconel 617 stud bolts go through severe testing before being shipped, including dimension inspection, material analysis check, and mechanical performance tests. Such tests ensure the bolts meet quality standards in industry requirements as far as strength, corrosion resistance, and high-pressure and high-temperature resistance.
The Fasteners Mart is a leading manufacturer and supplier of high-quality fasteners in Mumbai, India, with over 8 years of experience serving global industries.
