Request For Our Latest Prices On Hastelloy C276 Nuts in Mumbai, India!
The Mumbai, India-based Fasteners Mart is a reliable manufacturer and exporter of high-quality industrial fasteners, providing high-performance solutions to different industries across the world. Some of their flagship products include Hastelloy C276 Nuts, which are made from a high-quality Nickel-Molybdenum-Chromium alloy (UNS N10276). These nuts are available in different shapes like hex nuts, heavy hex nuts, lock nuts, and cap nuts, providing superior resistance to aggressive chemicals and harsh temperatures. Synthesized for demanding use, Hastelloy C276 Nuts exhibit strength, accuracy, and high corrosion resistance under severe operating conditions.
Hastelloy C276 Nuts contain about 57% Nickel, 16% Molybdenum, 15.5% Chromium, and 5% Iron, with minute quantities of Tungsten and Cobalt. They possess high mechanical properties of tensile strength of about 760 MPa and yield strength of about 300 MPa, and an elongation value of 40–45%. They are dense at 8.89 g/cm³ with a melting range of 1325°C–1370°C. These characteristics render Hastelloy C276 Nuts extremely reliable in corrosive, high-stress, and thermally critical industrial applications.
| Specifications | ASTM B574 / ASME SB574 |
|---|---|
| Fasteners size | Bolt / Screw Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Nuts Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Washers Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Machine Screws Size : M1.6 – M12 Self Tapping Screw Size : No.2 – No. 14 |
| Fasteners Length | 3 mm to 200 mm |
| Fastener Threads | UNF, BSW, BSF, METRIC, UNC or as required |
| Standard of High Nickel Alloy Fasteners | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Stud Bolt length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Surface Coating | Ptfe Coated High Nickel Alloy Fasteners Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Fasteners Finishing | High Nickel Alloy : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), High Nickel Alloy, Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide. |
| Grade | C | Mn | Si | Co | S | Ni | Cr | Fe | Mo | W | V | P |
| Hastelloy Fasteners | 0.010 max | 1.0 max | 0.08 max | 2.5 max | 0.03 max | Bal | 14.5 – 16.5 | 4 – 7 | 15 – 17 | 3 – 4.5 | 0.35 max | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy Fasteners | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Hastelloy C276 Nuts find wide application in chemical processing, marine, oil and gas, pollution control, and pharmaceutical industries. They are especially designed for fastening systems that are subjected to harsh chemicals like sulfuric acid, hydrochloric acid, and chlorine compounds. They are typically applied in heat exchangers, flue gas scrubbers, reactors, and pressure vessels. They are formulated to deliver secure and corrosion-free fastening under high-pressure and high-temperature conditions, with safety and performance in the harshest conditions.
The Fasteners Mart provides safe and timely delivery of Hastelloy C276 Nuts to both domestic and overseas markets. All orders are packed securely with bubble wrap, wooden crates, and corrugated boxes to ensure that there is no transit damage. Special packaging solutions can also be provided as per specific customer requirements.
The Fasteners Mart is a leading manufacturer and supplier of high-quality fasteners in Mumbai, India, with over 8 years of experience serving global industries.
