Request For Our Latest Prices On Hastelloy C276 Bolts in Mumbai, India!
Fasteners Mart, which has its operations base in Mumbai, India, is a leading producer and global supplier of precision fasteners of international standard renowned for durability and performance. Their excellent range of products includes Hastelloy C276 Bolts made of premium-quality Nickel-Molybdenum-Chromium alloy (UNS N10276). These bolts can be provided in numerous forms, such as hex bolts, U-bolts, socket head bolts, and anchor bolts. Built for harsh conditions, Hastelloy C276 Bolts have superior corrosion resistance and mechanical properties and are suited for application in highly corrosive and high-temperature industrial processes.
Hastelloy C276 Bolts consist of Nickel (57%), Molybdenum (16%), Chromium (15.5%), and Iron (5%), with trace amounts of Tungsten and Cobalt. They have very good mechanical properties, such as a tensile strength of approximately 760 MPa and a yield strength of about 300 MPa, with 40–45% elongation. They possess a density of 8.89 g/cm³ and a melting point in the range of 1325°C to 1370°C. These mechanical and physical characteristics make Hastelloy C276 Bolts suitable for conditions that demand strength, heat, and resistance against corrosion and chemical attack.
| Specifications | ASTM B574 / ASME SB574 |
|---|---|
| Fasteners size | Bolt / Screw Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Nuts Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Washers Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Machine Screws Size : M1.6 – M12 Self Tapping Screw Size : No.2 – No. 14 |
| Fasteners Length | 3 mm to 200 mm |
| Fastener Threads | UNF, BSW, BSF, METRIC, UNC or as required |
| Standard of High Nickel Alloy Fasteners | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Stud Bolt length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Surface Coating | Ptfe Coated High Nickel Alloy Fasteners Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Fasteners Finishing | High Nickel Alloy : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), High Nickel Alloy, Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide. |
| Grade | C | Mn | Si | Co | S | Ni | Cr | Fe | Mo | W | V | P |
| Hastelloy C276 Bolts | 0.010 max | 1.0 max | 0.08 max | 2.5 max | 0.03 max | Bal | 14.5 – 16.5 | 4 – 7 | 15 – 17 | 3 – 4.5 | 0.35 max | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 Bolts | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Hastelloy C276 Bolts find application in various chemical processing, petrochemical, power generation, marine, and wastewater treatment industries. Their remarkable resistance to oxidizing and reducing agents makes equipment such as heat exchangers, pressure vessels, and reactors ideal for usage. These bolts are particularly successful in environments filled with strong acids such as sulfuric, hydrochloric, and nitric acid. Their capability to uphold integrity in harsh chemical and high-stress environments provides long-term performance, which makes them a vital part in demanding and safety-critical industrial systems.
The Hastelloy C276 Bolts are delivered on time and safely by Fasteners Mart to the customers globally. Every bolt is properly packed in tough materials including wooden crates, bubble wraps, and corrugated boxes to avoid damage during transportation. Specialized packaging service can also be arranged according to client needs.
The Fasteners Mart is a leading manufacturer and supplier of high-quality fasteners in Mumbai, India, with over 8 years of experience serving global industries.
