Request For Our Latest Prices On Hastelloy C22 Bolts in Mumbai, India!
The Mumbai, India-based Fasteners Mart is a leading supplier and exporter of industrial fasteners of high performance. With a firm belief in maintaining high quality and customer satisfaction, the company provides a wide range of fastening solutions as per the diverse industrial requirements. Their top-of-the-line products include Hastelloy C22 Bolts, produced with a high-quality Nickel-Chromium-Molybdenum alloy (UNS N06022). These bolts are available in sizes like hex head, socket head, U-bolts, and anchor bolts. They are renowned for superior corrosion resistance and are specified for application under aggressive chemical and high-temperature conditions.
Hastelloy C22 Bolts are primarily composed of Nickel (56%), Chromium (22%), Molybdenum (13%), and small amounts of Iron, Cobalt, and Tungsten. Mechanically, they offer high strength with a tensile strength of around 690 MPa and a yield strength of approximately 310 MPa, along with an elongation of about 45%. Physically, the material has a density of 8.69 g/cm³ and a melting range between 1399–1410°C. These properties make Hastelloy C22 Bolts highly resistant to pitting, crevice corrosion, and stress corrosion cracking in harsh environments.
| Specifications | ASTM B574 / ASME SB574 |
|---|---|
| Fasteners size | Bolt / Screw Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Nuts Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Washers Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Machine Screws Size : M1.6 – M12 Self Tapping Screw Size : No.2 – No. 14 |
| Fasteners Length | 3 mm to 200 mm |
| Fastener Threads | UNF, BSW, BSF, METRIC, UNC or as required |
| Standard of High Nickel Alloy Fasteners | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Stud Bolt length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Surface Coating | Ptfe Coated High Nickel Alloy Fasteners Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Fasteners Finishing | High Nickel Alloy : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), High Nickel Alloy, Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide. |
| Grade | C | Mn | Si | Co | S | Ni | Cr | Fe | Mo | W | V | P |
| Hastelloy C22 Bolts | 0.010 max | 1.0 max | 0.08 max | 2.5 max | 0.03 max | Bal | 14.5 – 16.5 | 4 – 7 | 15 – 17 | 3 – 4.5 | 0.35 max | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C22 Bolts | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Hastelloy C22 Bolts find wide application in chemical processing, pharmaceuticals, marine engineering, and pollution control industries. They have superior resistance to reducing and oxidizing agents and are, therefore, the best choice to be used in reactors, heat exchangers, and pressure vessels. They are especially good at dealing with corrosive chemicals like sulfuric acid, hydrochloric acid, and wet chlorine. These bolts provide structural stability in systems under severe chemical exposure, and therefore, they are a popular selection for applications that require long-term durability and superior resistance to corrosive damage.
The Fasteners Mart ensures safe and timely delivery of Hastelloy C22 Bolts to domestic as well as international customers. Every bolt is packed securely with durable packaging materials like wooden crates, bubble wraps, and corrugated boxes to avoid damage during transportation. Special packaging arrangements are also available according to client requirements.
